TIP147T ST TRANS PNP DARL 100V 10A TO-220
TIP147T Images
TIP147T Images
TIP147T
  • Manufacturer: STMicroelectronics(ST)
  • Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-220-3
  • Description: TRANS PNP DARL 100V 10A TO-220
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
TIP147T Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
TIP147T Specifications:
  • MfrPart.: TIP147T
  • Mfr: STMicroelectronics
  • Description: TRANS PNP DARL 100V 10A TO-220
  • Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
  • Package: Tube
  • Series: -
  • PartStatus: Active
  • TransistorType: PNP - Darlington
  • Current-Collector(Ic)(Max): 10 A
  • Voltage-CollectorEmitterBreakdown(Max): 100 V
  • VceSaturation(Max)@IbIc: 3V @ 40mA, 10A
  • Current-CollectorCutoff(Max): 2mA
  • DCCurrentGain(hFE)(Min)@IcVce: 1000 @ 5A, 4V
  • Power-Max: 90 W
  • Frequency-Transition: -
  • OperatingTemperature: 150°C (TJ)
  • MountingType: Through Hole
  • Package/Case: TO-220-3
  • TIP147T STMicroelectronics, TRANS PNP DARL 100V 10A TO-220, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
