TIP145 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-218-3
- Description: TRANS PNP DARL 60V 10A TO-247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
TIP145 Specifications:
- MfrPart.: TIP145
- Mfr: STMicroelectronics
- Description: TRANS PNP DARL 60V 10A TO-247
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- TransistorType: PNP - Darlington
- Current-Collector(Ic)(Max): 10 A
- Voltage-CollectorEmitterBreakdown(Max): 60 V
- VceSaturation(Max)@IbIc: 3V @ 40mA, 10A
- Current-CollectorCutoff(Max): 2mA
- DCCurrentGain(hFE)(Min)@IcVce: 1000 @ 5A, 4V
- Power-Max: 125 W
- Frequency-Transition: -
- OperatingTemperature: 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-218-3
- TIP145 STMicroelectronics, TRANS PNP DARL 60V 10A TO-247, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
TIP145, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
