STY140NS10 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: MAX247™
- Description: MOSFET N-CH 100V 140A MAX247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STY140NS10 Specifications:
- MfrPart.: STY140NS10
- Mfr: STMicroelectronics
- Description: MOSFET N-CH 100V 140A MAX247
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: MESH OVERLAY™
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 100 V
- Current-ContinuousDrain(Id)@25°C: 140A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 11mOhm @ 70A, 10V
- Vgs(th)(Max)@Id: 4V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 600 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 12600 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 450W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: MAX247™
- STY140NS10 STMicroelectronics, MOSFET N-CH 100V 140A MAX247, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
