STWA75N60M6 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-247 Long Leads
- Description: MOSFET N-CH 600V 72A TO247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STWA75N60M6 Specifications:
- MfrPart.: STWA75N60M6
- Mfr: STMicroelectronics
- Description: MOSFET N-CH 600V 72A TO247
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: MDmesh™ M6
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 600 V
- Current-ContinuousDrain(Id)@25°C: 72A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 36mOhm @ 36A, 10V
- Vgs(th)(Max)@Id: 4.75V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 106 nC @ 10 V
- Vgs(Max): ±25V
- InputCapacitance(Ciss)(Max)@Vds: 4850 pF @ 100 V
- FETFeature: -
- PowerDissipation(Max): 446W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-247 Long Leads
- STWA75N60M6 STMicroelectronics, MOSFET N-CH 600V 72A TO247, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
