STW77N65M5 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-247
- Description: MOSFET N-CH 650V 69A TO247-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STW77N65M5 Specifications:
- MfrPart.: STW77N65M5
- Mfr: STMicroelectronics
- Description: MOSFET N-CH 650V 69A TO247-3
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: MDmesh™ V
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 650 V
- Current-ContinuousDrain(Id)@25°C: 69A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 38mOhm @ 34.5A, 10V
- Vgs(th)(Max)@Id: 5V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 200 nC @ 10 V
- Vgs(Max): 25V
- InputCapacitance(Ciss)(Max)@Vds: 9800 pF @ 100 V
- FETFeature: -
- PowerDissipation(Max): 400W (Tc)
- OperatingTemperature: 150°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-247
- STW77N65M5 STMicroelectronics, MOSFET N-CH 650V 69A TO247-3, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
STW77N65M5, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
