STW26NM50 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-247-3
- Description: MOSFET N-CH 500V 30A TO247-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STW26NM50 Specifications:
- MfrPart.: STW26NM50
- Mfr: STMicroelectronics
- Description: MOSFET N-CH 500V 30A TO247-3
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: MDmesh™
- PartStatus: Not For New Designs
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 500 V
- Current-ContinuousDrain(Id)@25°C: 30A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 120mOhm @ 13A, 10V
- Vgs(th)(Max)@Id: 5V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 106 nC @ 10 V
- Vgs(Max): ±30V
- InputCapacitance(Ciss)(Max)@Vds: 3000 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 313W (Tc)
- OperatingTemperature: 150°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-247-3
- STW26NM50 STMicroelectronics, MOSFET N-CH 500V 30A TO247-3, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
STW26NM50, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
