STW2040 ST TRANS NPN 500V 20A TO-247
STW2040 Images
STW2040 Images
  • Manufacturer: STMicroelectronics(ST)
  • Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-247-3
  • Description: TRANS NPN 500V 20A TO-247
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
STW2040 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
STW2040 Specifications:
  • MfrPart.: STW2040
  • Mfr: STMicroelectronics
  • Description: TRANS NPN 500V 20A TO-247
  • Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
  • Package: Tube
  • Series: -
  • PartStatus: Obsolete
  • TransistorType: NPN
  • Current-Collector(Ic)(Max): 20 A
  • Voltage-CollectorEmitterBreakdown(Max): 500 V
  • VceSaturation(Max)@IbIc: 500mV @ 1.2A, 6A
  • Current-CollectorCutoff(Max): 250µA
  • DCCurrentGain(hFE)(Min)@IcVce: 15 @ 6A, 5V
  • Power-Max: 125 W
  • Frequency-Transition: -
  • OperatingTemperature: 150°C (TJ)
  • MountingType: Through Hole
  • Package/Case: TO-247-3
  • STW2040 STMicroelectronics, TRANS NPN 500V 20A TO-247, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
STW2040, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
