STW14NM50FD Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-247-3
- Description: MOSFET N-CH 500V 14A TO247-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STW14NM50FD Specifications:
- MfrPart.: STW14NM50FD
- Mfr: STMicroelectronics
- Description: MOSFET N-CH 500V 14A TO247-3
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: FDmesh™
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 500 V
- Current-ContinuousDrain(Id)@25°C: 14A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 400mOhm @ 6A, 10V
- Vgs(th)(Max)@Id: 5V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 12 nC @ 10 V
- Vgs(Max): ±30V
- InputCapacitance(Ciss)(Max)@Vds: 1000 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 160W (Tc)
- OperatingTemperature: -65°C ~ 150°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-247-3
- STW14NM50FD STMicroelectronics, MOSFET N-CH 500V 14A TO247-3, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
STW14NM50FD, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
