STW12N120K5 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-247
- Description: MOSFET N-CH 1200V 12A TO247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STW12N120K5 Specifications:
- MfrPart.: STW12N120K5
- Mfr: STMicroelectronics
- Description: MOSFET N-CH 1200V 12A TO247
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: MDmesh™ K5
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 1200 V
- Current-ContinuousDrain(Id)@25°C: 12A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 690mOhm @ 6A, 10V
- Vgs(th)(Max)@Id: 5V @ 100µA
- GateCharge(Qg)(Max)@Vgs: 44.2 nC @ 10 V
- Vgs(Max): ±30V
- InputCapacitance(Ciss)(Max)@Vds: 1370 pF @ 100 V
- FETFeature: -
- PowerDissipation(Max): 250W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-247
- STW12N120K5 STMicroelectronics, MOSFET N-CH 1200V 12A TO247, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
STW12N120K5, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
