STU150N3LLH6 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: I-PAK
- Description: MOSFET N-CH 30V 80A IPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STU150N3LLH6 Specifications:
- MfrPart.: STU150N3LLH6
- Mfr: STMicroelectronics
- Description: MOSFET N-CH 30V 80A IPAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: DeepGATE™, STripFET™ VI
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 80A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 3.3mOhm @ 40A, 10V
- Vgs(th)(Max)@Id: 2.5V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 40 nC @ 4.5 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 4040 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 110W (Tc)
- OperatingTemperature: 175°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: I-PAK
- STU150N3LLH6 STMicroelectronics, MOSFET N-CH 30V 80A IPAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
STU150N3LLH6, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
