STT5PF20V Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: SOT-23-6
- Description: MOSFET P-CH 20V 5A SOT23-6
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STT5PF20V Specifications:
- MfrPart.: STT5PF20V
- Mfr: STMicroelectronics
- Description: MOSFET P-CH 20V 5A SOT23-6
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: STripFET™ II
- PartStatus: Obsolete
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 20 V
- Current-ContinuousDrain(Id)@25°C: 5A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 2.5V, 4.5V
- RdsOn(Max)@IdVgs: 80mOhm @ 2.5A, 4.5V
- Vgs(th)(Max)@Id: 450mV @ 250µA
- GateCharge(Qg)(Max)@Vgs: 4.5 nC @ 2.5 V
- Vgs(Max): ±8V
- InputCapacitance(Ciss)(Max)@Vds: 412 pF @ 15 V
- FETFeature: -
- PowerDissipation(Max): 1.6W (Tc)
- OperatingTemperature: 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: SOT-23-6
- STT5PF20V STMicroelectronics, MOSFET P-CH 20V 5A SOT23-6, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
