STT2PF60L Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: SOT-23-6
- Description: MOSFET P-CH 60V 2A SOT23-6
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STT2PF60L Specifications:
- MfrPart.: STT2PF60L
- Mfr: STMicroelectronics
- Description: MOSFET P-CH 60V 2A SOT23-6
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: STripFET™ II
- PartStatus: Obsolete
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 60 V
- Current-ContinuousDrain(Id)@25°C: 2A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 250mOhm @ 1A, 10V
- Vgs(th)(Max)@Id: 1V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 7 nC @ 10 V
- Vgs(Max): ±15V
- InputCapacitance(Ciss)(Max)@Vds: 313 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 1.6W (Tc)
- OperatingTemperature: 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: SOT-23-6
- STT2PF60L STMicroelectronics, MOSFET P-CH 60V 2A SOT23-6, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
