STS5DNF20V Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays Package/Case: 8-SOIC (0.154, 3.90mm Width)
- Description: MOSFET 2N-CH 20V 5A 8-SOIC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STS5DNF20V Specifications:
- MfrPart.: STS5DNF20V
- Mfr: STMicroelectronics
- Description: MOSFET 2N-CH 20V 5A 8-SOIC
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: STripFET™ II
- PartStatus: Obsolete
- FETType: 2 N-Channel (Dual)
- FETFeature: Logic Level Gate
- DraintoSourceVoltage(Vdss): 20V
- Current-ContinuousDrain(Id)@25°C: 5A
- RdsOn(Max)@IdVgs: 40mOhm @ 2.5A, 4.5V
- Vgs(th)(Max)@Id: 600mV @ 250µA
- GateCharge(Qg)(Max)@Vgs: 11.5nC @ 4.5V
- InputCapacitance(Ciss)(Max)@Vds: 460pF @ 25V
- Power-Max: 2W
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: 8-SOIC (0.154, 3.90mm Width)
- STS5DNF20V STMicroelectronics, MOSFET 2N-CH 20V 5A 8-SOIC, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
STS5DNF20V, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
