STS4NF100 ST MOSFET N-CH 100V 4A 8SO
STS4NF100 Images
STS4NF100 Images
  • Manufacturer: STMicroelectronics(ST)
  • Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: 8-SOIC
  • Description: MOSFET N-CH 100V 4A 8SO
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
STS4NF100 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
STS4NF100 Specifications:
  • MfrPart.: STS4NF100
  • Mfr: STMicroelectronics
  • Description: MOSFET N-CH 100V 4A 8SO
  • Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
  • Package: Tape & Reel (TR),Cut Tape (CT)
  • Series: STripFET™ II
  • PartStatus: Obsolete
  • FETType: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • DraintoSourceVoltage(Vdss): 100 V
  • Current-ContinuousDrain(Id)@25°C: 4A (Tc)
  • DriveVoltage(MaxRdsOnMinRdsOn): 10V
  • RdsOn(Max)@IdVgs: 70mOhm @ 2A, 10V
  • Vgs(th)(Max)@Id: 4V @ 250µA
  • GateCharge(Qg)(Max)@Vgs: 41 nC @ 10 V
  • Vgs(Max): ±20V
  • InputCapacitance(Ciss)(Max)@Vds: 870 pF @ 25 V
  • FETFeature: -
  • PowerDissipation(Max): 2.5W (Ta)
  • OperatingTemperature: -55°C ~ 150°C (TJ)
  • MountingType: Surface Mount
  • SupplierDevicePackage: 8-SOIC
  • STS4NF100 STMicroelectronics, MOSFET N-CH 100V 4A 8SO, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
STS4NF100, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
