STQ1NC45R-AP Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-92-3
- Description: MOSFET N-CH 450V 500MA TO92-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STQ1NC45R-AP Specifications:
- MfrPart.: STQ1NC45R-AP
- Mfr: STMicroelectronics
- Description: MOSFET N-CH 450V 500MA TO92-3
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Cut Tape (CT),Tape & Box (TB)
- Series: SuperMESH™
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 450 V
- Current-ContinuousDrain(Id)@25°C: 500mA (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 4.5Ohm @ 500mA, 10V
- Vgs(th)(Max)@Id: 3.7V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 7 nC @ 10 V
- Vgs(Max): ±30V
- InputCapacitance(Ciss)(Max)@Vds: 160 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 3.1W (Tc)
- OperatingTemperature: -65°C ~ 150°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-92-3
- STQ1NC45R-AP STMicroelectronics, MOSFET N-CH 450V 500MA TO92-3, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
STQ1NC45R-AP, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
