STPS20H100CG ST DIODE ARRAY SCHOTTKY 100V D2PAK
STPS20H100CG Images
STPS20H100CG Images
  • Manufacturer: STMicroelectronics(ST)
  • Category: Discrete Semiconductor Products~Diodes - Rectifiers - Arrays Package / Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
  • Description: DIODE ARRAY SCHOTTKY 100V D2PAK
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
STPS20H100CG Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
STPS20H100CG Specifications:
  • Mfr Part: STPS20H100CG
  • Mfr: STMicroelectronics
  • Description: DIODE ARRAY SCHOTTKY 100V D2PAK
  • Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Arrays
  • Item12: Tube
  • Series: -
  • Part Status: Active
  • Diode Configuration: 1 Pair Common Cathode
  • Diode Type: Schottky
  • Voltage - DC Reverse (Vr) (Max): 100 V
  • Current - Average Rectified (Io) (per Diode): 10A
  • Voltage - Forward (Vf) (Max) @ If: 770 mV @ 10 A
  • Speed: Fast Recovery =< 500ns, > 200mA (Io)
  • Current - Reverse Leakage @ Vr: 4.5 µA @ 100 V
  • Operating Temperature - Junction: 175°C (Max)
  • Mounting Type: Surface Mount
  • Package / Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
  • STPS20H100CG STMicroelectronics, DIODE ARRAY SCHOTTKY 100V D2PAK, Discrete Semiconductor Products~Diodes - Rectifiers - Arrays
STPS20H100CG, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
