STPS15SM80CFP Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Diodes - Rectifiers - Arrays Package / Case: TO-220-3 Full Pack
- Description: DIODE ARRAY SCHOTTKY 80V TO220FP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STPS15SM80CFP Specifications:
- Mfr Part: STPS15SM80CFP
- Mfr: STMicroelectronics
- Description: DIODE ARRAY SCHOTTKY 80V TO220FP
- Product Category: Discrete Semiconductor Products~Diodes - Rectifiers - Arrays
- Item12: Tube
- Series: -
- Part Status: Obsolete
- Diode Configuration: 1 Pair Common Cathode
- Diode Type: Schottky
- Voltage - DC Reverse (Vr) (Max): 80 V
- Current - Average Rectified (Io) (per Diode): 7.5A
- Voltage - Forward (Vf) (Max) @ If: 780 mV @ 7.5 A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Current - Reverse Leakage @ Vr: 20 µA @ 80 V
- Operating Temperature - Junction: 175°C (Max)
- Mounting Type: Through Hole
- Package / Case: TO-220-3 Full Pack
- STPS15SM80CFP STMicroelectronics, DIODE ARRAY SCHOTTKY 80V TO220FP, Discrete Semiconductor Products~Diodes - Rectifiers - Arrays
STPS15SM80CFP, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
