STP9NM40N Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-220AB
- Description: MOSFET N-CH 400V 5.6A TO220
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STP9NM40N Specifications:
- MfrPart.: STP9NM40N
- Mfr: STMicroelectronics
- Description: MOSFET N-CH 400V 5.6A TO220
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: MDmesh™ II
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 400 V
- Current-ContinuousDrain(Id)@25°C: 5.6A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 790mOhm @ 2.5A, 10V
- Vgs(th)(Max)@Id: 4V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 14 nC @ 10 V
- Vgs(Max): ±25V
- InputCapacitance(Ciss)(Max)@Vds: 365 pF @ 50 V
- FETFeature: -
- PowerDissipation(Max): 60W (Tc)
- OperatingTemperature: 150°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-220AB
- STP9NM40N STMicroelectronics, MOSFET N-CH 400V 5.6A TO220, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
STP9NM40N, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
