STP45N40DM2AG ST MOSFET N-CH 400V 38A TO220
STP45N40DM2AG Images
STP45N40DM2AG Images
  • Manufacturer: STMicroelectronics(ST)
  • Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-220AB
  • Description: MOSFET N-CH 400V 38A TO220
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
STP45N40DM2AG Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
STP45N40DM2AG Specifications:
  • MfrPart.: STP45N40DM2AG
  • Mfr: STMicroelectronics
  • Description: MOSFET N-CH 400V 38A TO220
  • Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
  • Package: Tube
  • Series: Automotive, AEC-Q101, MDmesh™ DM2
  • PartStatus: Active
  • FETType: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • DraintoSourceVoltage(Vdss): 400 V
  • Current-ContinuousDrain(Id)@25°C: 38A (Tc)
  • DriveVoltage(MaxRdsOnMinRdsOn): 10V
  • RdsOn(Max)@IdVgs: 72mOhm @ 19A, 10V
  • Vgs(th)(Max)@Id: 5V @ 250µA
  • GateCharge(Qg)(Max)@Vgs: 56 nC @ 10 V
  • Vgs(Max): ±25V
  • InputCapacitance(Ciss)(Max)@Vds: 2600 pF @ 100 V
  • FETFeature: -
  • PowerDissipation(Max): 250W (Tc)
  • OperatingTemperature: -55°C ~ 150°C (TJ)
  • MountingType: Through Hole
  • SupplierDevicePackage: TO-220AB
  • STP45N40DM2AG STMicroelectronics, MOSFET N-CH 400V 38A TO220, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
STP45N40DM2AG, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
