STP25N80K5 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-220AB
- Description: MOSFET N-CH 800V 19.5A TO220
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STP25N80K5 Specifications:
- MfrPart.: STP25N80K5
- Mfr: STMicroelectronics
- Description: MOSFET N-CH 800V 19.5A TO220
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: SuperMESH5™
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 800 V
- Current-ContinuousDrain(Id)@25°C: 19.5A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 260mOhm @ 19.5A, 10V
- Vgs(th)(Max)@Id: 5V @ 100µA
- GateCharge(Qg)(Max)@Vgs: 40 nC @ 10 V
- Vgs(Max): ±30V
- InputCapacitance(Ciss)(Max)@Vds: 1600 pF @ 100 V
- FETFeature: -
- PowerDissipation(Max): 250W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-220AB
- STP25N80K5 STMicroelectronics, MOSFET N-CH 800V 19.5A TO220, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
