STP16NF06 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-220AB
- Description: MOSFET N-CH 60V 16A TO220AB
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STP16NF06 Specifications:
- MfrPart.: STP16NF06
- Mfr: STMicroelectronics
- Description: MOSFET N-CH 60V 16A TO220AB
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: STripFET™ II
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 60 V
- Current-ContinuousDrain(Id)@25°C: 16A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 100mOhm @ 8A, 10V
- Vgs(th)(Max)@Id: 4V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 13 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 315 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 45W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-220AB
- STP16NF06 STMicroelectronics, MOSFET N-CH 60V 16A TO220AB, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
STP16NF06, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
