STP12NM50FP ST MOSFET N-CH 500V 12A TO220FP
STP12NM50FP Images
STP12NM50FP Images
  • Manufacturer: STMicroelectronics(ST)
  • Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-220FP
  • Description: MOSFET N-CH 500V 12A TO220FP
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
STP12NM50FP Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
STP12NM50FP Specifications:
  • MfrPart.: STP12NM50FP
  • Mfr: STMicroelectronics
  • Description: MOSFET N-CH 500V 12A TO220FP
  • Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
  • Package: Tube
  • Series: MDmesh™
  • PartStatus: Active
  • FETType: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • DraintoSourceVoltage(Vdss): 500 V
  • Current-ContinuousDrain(Id)@25°C: 12A (Tc)
  • DriveVoltage(MaxRdsOnMinRdsOn): 10V
  • RdsOn(Max)@IdVgs: 350mOhm @ 6A, 10V
  • Vgs(th)(Max)@Id: 5V @ 50µA
  • GateCharge(Qg)(Max)@Vgs: 39 nC @ 10 V
  • Vgs(Max): ±30V
  • InputCapacitance(Ciss)(Max)@Vds: 1000 pF @ 25 V
  • FETFeature: -
  • PowerDissipation(Max): 35W (Tc)
  • OperatingTemperature: -65°C ~ 150°C (TJ)
  • MountingType: Through Hole
  • SupplierDevicePackage: TO-220FP
  • STP12NM50FP STMicroelectronics, MOSFET N-CH 500V 12A TO220FP, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
STP12NM50FP, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
