STP100N8F6 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-220AB
- Description: MOSFET N-CH 80V 100A TO220
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STP100N8F6 Specifications:
- MfrPart.: STP100N8F6
- Mfr: STMicroelectronics
- Description: MOSFET N-CH 80V 100A TO220
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: STripFET™ F6
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 80 V
- Current-ContinuousDrain(Id)@25°C: 100A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 9mOhm @ 50A, 10V
- Vgs(th)(Max)@Id: 4V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 100 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 5955 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 176W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-220AB
- STP100N8F6 STMicroelectronics, MOSFET N-CH 80V 100A TO220, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
STP100N8F6, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
