STL8P2UH7 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: PowerFlat™ (2x2)
- Description: MOSFET P-CH 20V 8A POWERFLAT
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STL8P2UH7 Specifications:
- MfrPart.: STL8P2UH7
- Mfr: STMicroelectronics
- Description: MOSFET P-CH 20V 8A POWERFLAT
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: DeepGATE™, STripFET™ VII
- PartStatus: Obsolete
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 20 V
- Current-ContinuousDrain(Id)@25°C: 8A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 1.5V, 4.5V
- RdsOn(Max)@IdVgs: 22.5mOhm @ 4A, 4.5V
- Vgs(th)(Max)@Id: 1V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 22 nC @ 4.5 V
- Vgs(Max): ±8V
- InputCapacitance(Ciss)(Max)@Vds: 2390 pF @ 16 V
- FETFeature: -
- PowerDissipation(Max): 2.4W (Tc)
- OperatingTemperature: 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: PowerFlat™ (2x2)
- STL8P2UH7 STMicroelectronics, MOSFET P-CH 20V 8A POWERFLAT, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
