STL85N6F3 ST MOSFET N-CH 60V 85A POWERFLAT
STL85N6F3 Images
STL85N6F3 Images
  • Manufacturer: STMicroelectronics(ST)
  • Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: PowerFlat™ (5x6)
  • Description: MOSFET N-CH 60V 85A POWERFLAT
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
STL85N6F3 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
STL85N6F3 Specifications:
  • MfrPart.: STL85N6F3
  • Mfr: STMicroelectronics
  • Description: MOSFET N-CH 60V 85A POWERFLAT
  • Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
  • Package: Tape & Reel (TR),Cut Tape (CT)
  • Series: STripFET™
  • PartStatus: Obsolete
  • FETType: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • DraintoSourceVoltage(Vdss): 60 V
  • Current-ContinuousDrain(Id)@25°C: 85A (Tc)
  • DriveVoltage(MaxRdsOnMinRdsOn): 10V
  • RdsOn(Max)@IdVgs: 5.7mOhm @ 8.5A, 10V
  • Vgs(th)(Max)@Id: 2V @ 250µA
  • GateCharge(Qg)(Max)@Vgs: 60 nC @ 10 V
  • Vgs(Max): ±20V
  • InputCapacitance(Ciss)(Max)@Vds: 3400 pF @ 25 V
  • FETFeature: -
  • PowerDissipation(Max): 80W (Tc)
  • OperatingTemperature: -55°C ~ 150°C (TJ)
  • MountingType: Surface Mount
  • SupplierDevicePackage: PowerFlat™ (5x6)
  • STL85N6F3 STMicroelectronics, MOSFET N-CH 60V 85A POWERFLAT, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
STL85N6F3, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
