STL7N80K5 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: PowerFlat™ (5x6)
- Description: MOSFET N-CH 800V 3.6A POWERFLAT
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STL7N80K5 Specifications:
- MfrPart.: STL7N80K5
- Mfr: STMicroelectronics
- Description: MOSFET N-CH 800V 3.6A POWERFLAT
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: SuperMESH5™
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 800 V
- Current-ContinuousDrain(Id)@25°C: 3.6A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 1.2Ohm @ 3A, 10V
- Vgs(th)(Max)@Id: 5V @ 100µA
- GateCharge(Qg)(Max)@Vgs: 13.4 nC @ 10 V
- Vgs(Max): ±30V
- InputCapacitance(Ciss)(Max)@Vds: 360 pF @ 100 V
- FETFeature: -
- PowerDissipation(Max): 42W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: PowerFlat™ (5x6)
- STL7N80K5 STMicroelectronics, MOSFET N-CH 800V 3.6A POWERFLAT, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
