STL260N4LF7 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: PowerFlat™ (5x6)
- Description: N-CHANNEL 40 V, 0.00085 OHM TYP.
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STL260N4LF7 Specifications:
- MfrPart.: STL260N4LF7
- Mfr: STMicroelectronics
- Description: N-CHANNEL 40 V, 0.00085 OHM TYP.
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: STripFET™ F7
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 40 V
- Current-ContinuousDrain(Id)@25°C: 120A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 1.1mOhm @ 25A, 10V
- Vgs(th)(Max)@Id: 2.5V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 42 nC @ 4.5 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 6000 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 188W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: PowerFlat™ (5x6)
- STL260N4LF7 STMicroelectronics, N-CHANNEL 40 V, 0.00085 OHM TYP., Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
STL260N4LF7, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
