STL24NM60N Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: PowerFlat™ (8x8) HV
- Description: MOSFET N-CH 600V 16A POWERFLAT
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STL24NM60N Specifications:
- MfrPart.: STL24NM60N
- Mfr: STMicroelectronics
- Description: MOSFET N-CH 600V 16A POWERFLAT
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: MDmesh™ II
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 600 V
- Current-ContinuousDrain(Id)@25°C: 3.3A (Ta), 16A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 215mOhm @ 8A, 10V
- Vgs(th)(Max)@Id: 5V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 46 nC @ 10 V
- Vgs(Max): ±25V
- InputCapacitance(Ciss)(Max)@Vds: 1400 pF @ 50 V
- FETFeature: -
- PowerDissipation(Max): 3W (Ta), 125W (Tc)
- OperatingTemperature: 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: PowerFlat™ (8x8) HV
- STL24NM60N STMicroelectronics, MOSFET N-CH 600V 16A POWERFLAT, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
STL24NM60N, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
