STL225N6F7AG ST MOSFET N-CH 60V 120A POWERFLAT
STL225N6F7AG Images
STL225N6F7AG Images
  • Manufacturer: STMicroelectronics(ST)
  • Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: PowerFlat™ (5x6)
  • Description: MOSFET N-CH 60V 120A POWERFLAT
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
STL225N6F7AG Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
STL225N6F7AG Specifications:
  • MfrPart.: STL225N6F7AG
  • Mfr: STMicroelectronics
  • Description: MOSFET N-CH 60V 120A POWERFLAT
  • Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
  • Package: Tape & Reel (TR),Cut Tape (CT)
  • Series: Automotive, AEC-Q101, STripFET™ F7
  • PartStatus: Active
  • FETType: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • DraintoSourceVoltage(Vdss): 60 V
  • Current-ContinuousDrain(Id)@25°C: 120A (Tc)
  • DriveVoltage(MaxRdsOnMinRdsOn): 10V
  • RdsOn(Max)@IdVgs: 1.4mOhm @ 60A, 10V
  • Vgs(th)(Max)@Id: 4V @ 250µA
  • GateCharge(Qg)(Max)@Vgs: 98 nC @ 10 V
  • Vgs(Max): ±20V
  • InputCapacitance(Ciss)(Max)@Vds: 6500 pF @ 25 V
  • FETFeature: -
  • PowerDissipation(Max): 188W (Tc)
  • OperatingTemperature: -55°C ~ 175°C (TJ)
  • MountingType: Surface Mount
  • SupplierDevicePackage: PowerFlat™ (5x6)
  • STL225N6F7AG STMicroelectronics, MOSFET N-CH 60V 120A POWERFLAT, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
STL225N6F7AG, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
