STL20N6F7 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: PowerFlat™ (3.3x3.3)
- Description: MOSFET N-CH 60V 100A POWERFLAT
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STL20N6F7 Specifications:
- MfrPart.: STL20N6F7
- Mfr: STMicroelectronics
- Description: MOSFET N-CH 60V 100A POWERFLAT
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: STripFET™ F7
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 60 V
- Current-ContinuousDrain(Id)@25°C: 100A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 5.4mOhm @ 10A, 10V
- Vgs(th)(Max)@Id: 4V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 25 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 1600 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 3W (Ta), 78W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: PowerFlat™ (3.3x3.3)
- STL20N6F7 STMicroelectronics, MOSFET N-CH 60V 100A POWERFLAT, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
STL20N6F7, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
