STL20DNF06LAG Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays Package/Case: 8-PowerVDFN
- Description: MOSFET 2NCH 60V 20A POWERFLAT
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STL20DNF06LAG Specifications:
- MfrPart.: STL20DNF06LAG
- Mfr: STMicroelectronics
- Description: MOSFET 2NCH 60V 20A POWERFLAT
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
- Package: Tape & Reel (TR)
- Series: Automotive, AEC-Q101
- PartStatus: Obsolete
- FETType: 2 N-Channel (Dual)
- FETFeature: Logic Level Gate
- DraintoSourceVoltage(Vdss): 60V
- Current-ContinuousDrain(Id)@25°C: 20A
- RdsOn(Max)@IdVgs: 40mOhm @ 4A, 10V
- Vgs(th)(Max)@Id: 2.5V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 22.5nC @ 10V
- InputCapacitance(Ciss)(Max)@Vds: 670pF @ 25V
- Power-Max: 75W
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- Package/Case: 8-PowerVDFN
- STL20DNF06LAG STMicroelectronics, MOSFET 2NCH 60V 20A POWERFLAT, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Arrays
STL20DNF06LAG, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
