STL16N1VH5 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: PowerFlat™ (3.3x3.3)
- Description: MOSFET N-CH 12V 16A POWERFLAT
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STL16N1VH5 Specifications:
- MfrPart.: STL16N1VH5
- Mfr: STMicroelectronics
- Description: MOSFET N-CH 12V 16A POWERFLAT
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: STripFET™ V
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 12 V
- Current-ContinuousDrain(Id)@25°C: 16A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 2.5V, 4.5V
- RdsOn(Max)@IdVgs: 3mOhm @ 8A, 4.5V
- Vgs(th)(Max)@Id: 500mV @ 250µA
- GateCharge(Qg)(Max)@Vgs: 26.5 nC @ 4.5 V
- Vgs(Max): ±8V
- InputCapacitance(Ciss)(Max)@Vds: 2085 pF @ 12 V
- FETFeature: -
- PowerDissipation(Max): 2W (Ta), 50W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: PowerFlat™ (3.3x3.3)
- STL16N1VH5 STMicroelectronics, MOSFET N-CH 12V 16A POWERFLAT, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
STL16N1VH5, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
