STL15N60M2-EP Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: PowerFlat™ (5x6) HV
- Description: MOSFET N-CH 600V 7A POWERFLAT HV
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STL15N60M2-EP Specifications:
- MfrPart.: STL15N60M2-EP
- Mfr: STMicroelectronics
- Description: MOSFET N-CH 600V 7A POWERFLAT HV
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: MDmesh™ M2-EP
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 600 V
- Current-ContinuousDrain(Id)@25°C: 7A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 418mOhm @ 4.5A, 10V
- Vgs(th)(Max)@Id: 4.75V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 17 nC @ 10 V
- Vgs(Max): ±25V
- InputCapacitance(Ciss)(Max)@Vds: 590 pF @ 100 V
- FETFeature: -
- PowerDissipation(Max): 55W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: PowerFlat™ (5x6) HV
- STL15N60M2-EP STMicroelectronics, MOSFET N-CH 600V 7A POWERFLAT HV, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
STL15N60M2-EP, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
