STL100N10F7 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: PowerFlat™ (5x6)
- Description: MOSFET N-CH 100V 80A POWERFLAT
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STL100N10F7 Specifications:
- MfrPart.: STL100N10F7
- Mfr: STMicroelectronics
- Description: MOSFET N-CH 100V 80A POWERFLAT
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: DeepGATE™, STripFET™ VII
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 100 V
- Current-ContinuousDrain(Id)@25°C: 80A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 7.3mOhm @ 19A, 10V
- Vgs(th)(Max)@Id: 4V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 80 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 5680 pF @ 50 V
- FETFeature: -
- PowerDissipation(Max): 5W (Ta), 100W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: PowerFlat™ (5x6)
- STL100N10F7 STMicroelectronics, MOSFET N-CH 100V 80A POWERFLAT, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
STL100N10F7, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
