STK38N3LLH5 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: PolarPak®
- Description: MOSFET N-CH 30V 38A POLARPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STK38N3LLH5 Specifications:
- MfrPart.: STK38N3LLH5
- Mfr: STMicroelectronics
- Description: MOSFET N-CH 30V 38A POLARPAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: STripFET™ V
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 38A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 1.55mOhm @ 19A, 10V
- Vgs(th)(Max)@Id: 2.5V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 41.7 nC @ 4.5 V
- Vgs(Max): ±22V
- InputCapacitance(Ciss)(Max)@Vds: 4640 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 5.2W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: PolarPak®
- STK38N3LLH5 STMicroelectronics, MOSFET N-CH 30V 38A POLARPAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
STK38N3LLH5, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
