STH52N10LF3-2AG Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: H2Pak-2
- Description: MOSFET N-CH 100V 52A H2PAK-2
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STH52N10LF3-2AG Specifications:
- MfrPart.: STH52N10LF3-2AG
- Mfr: STMicroelectronics
- Description: MOSFET N-CH 100V 52A H2PAK-2
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: STripFET™ F3
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 100 V
- Current-ContinuousDrain(Id)@25°C: 52A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 5V, 10V
- RdsOn(Max)@IdVgs: 20mOhm @ 26A, 10V
- Vgs(th)(Max)@Id: 2.5V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 18.5 nC @ 5 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 1900 pF @ 400 V
- FETFeature: -
- PowerDissipation(Max): 110W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: H2Pak-2
- STH52N10LF3-2AG STMicroelectronics, MOSFET N-CH 100V 52A H2PAK-2, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
STH52N10LF3-2AG, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
