STH300NH02L-6 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: H²PAK
- Description: MOSFET N-CH 24V 180A H2PAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STH300NH02L-6 Specifications:
- MfrPart.: STH300NH02L-6
- Mfr: STMicroelectronics
- Description: MOSFET N-CH 24V 180A H2PAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: Automotive, AEC-Q101, STripFET™ III
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 24 V
- Current-ContinuousDrain(Id)@25°C: 180A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 5V, 10V
- RdsOn(Max)@IdVgs: 1.2mOhm @ 80A, 10V
- Vgs(th)(Max)@Id: 1V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 109 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 7050 pF @ 15 V
- FETFeature: -
- PowerDissipation(Max): 300W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: H²PAK
- STH300NH02L-6 STMicroelectronics, MOSFET N-CH 24V 180A H2PAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
STH300NH02L-6, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
