STGWT40H65FB Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-3P-3, SC-65-3
- Description: IGBT 650V 80A 283W TO3P-3L
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STGWT40H65FB Specifications:
- MfrPart.: STGWT40H65FB
- Mfr: STMicroelectronics
- Description: IGBT 650V 80A 283W TO3P-3L
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 650 V
- Current-Collector(Ic)(Max): 80 A
- Current-CollectorPulsed(Icm): 160 A
- Vce(on)(Max)@VgeIc: 2.3V @ 15V, 40A
- Power-Max: 283 W
- SwitchingEnergy: 498mJ (on), 363mJ (off)
- InputType: Standard
- GateCharge: 210 nC
- Td(on/off)@25°C: 40ns/142ns
- TestCondition: 400V, 40A, 5Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-3P-3, SC-65-3
- STGWT40H65FB STMicroelectronics, IGBT 650V 80A 283W TO3P-3L, Discrete Semiconductor Products~Transistors - IGBTs - Single
STGWT40H65FB, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
