STGWA60V60DF Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT BIPO 600V 60A TO247-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STGWA60V60DF Specifications:
- MfrPart.: STGWA60V60DF
- Mfr: STMicroelectronics
- Description: IGBT BIPO 600V 60A TO247-3
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 80 A
- Current-CollectorPulsed(Icm): 240 A
- Vce(on)(Max)@VgeIc: 2.3V @ 15V, 60A
- Power-Max: 375 W
- SwitchingEnergy: 750µJ (on), 550µJ (off)
- InputType: Standard
- GateCharge: 334 nC
- Td(on/off)@25°C: 60ns/208ns
- TestCondition: 400V, 60A, 4.7Ohm, 15V
- ReverseRecoveryTime(trr): 74 ns
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- STGWA60V60DF STMicroelectronics, IGBT BIPO 600V 60A TO247-3, Discrete Semiconductor Products~Transistors - IGBTs - Single
STGWA60V60DF, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
