STGWA40N120KD Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT 1200V 80A 240W TO247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STGWA40N120KD Specifications:
- MfrPart.: STGWA40N120KD
- Mfr: STMicroelectronics
- Description: IGBT 1200V 80A 240W TO247
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: PowerMESH™
- PartStatus: Obsolete
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 80 A
- Current-CollectorPulsed(Icm): 120 A
- Vce(on)(Max)@VgeIc: 3.85V @ 15V, 30A
- Power-Max: 240 W
- SwitchingEnergy: 3.7mJ (on), 5.7mJ (off)
- InputType: Standard
- GateCharge: 126 nC
- Td(on/off)@25°C: 48ns/338ns
- TestCondition: 960V, 30A, 10Ohm, 15V
- ReverseRecoveryTime(trr): 84 ns
- OperatingTemperature: -55°C ~ 125°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- STGWA40N120KD STMicroelectronics, IGBT 1200V 80A 240W TO247, Discrete Semiconductor Products~Transistors - IGBTs - Single
