STGWA40H65DFB Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT TRENCH 650V 80A TO247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STGWA40H65DFB Specifications:
- MfrPart.: STGWA40H65DFB
- Mfr: STMicroelectronics
- Description: IGBT TRENCH 650V 80A TO247
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: HB
- PartStatus: Active
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 650 V
- Current-Collector(Ic)(Max): 80 A
- Current-CollectorPulsed(Icm): 160 A
- Vce(on)(Max)@VgeIc: 2V @ 15V, 40A
- Power-Max: 283 W
- SwitchingEnergy: 498µJ (on), 363µJ (off)
- InputType: Standard
- GateCharge: 210 nC
- Td(on/off)@25°C: 40ns/142ns
- TestCondition: 400V, 40A, 5Ohm, 15V
- ReverseRecoveryTime(trr): 62 ns
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- STGWA40H65DFB STMicroelectronics, IGBT TRENCH 650V 80A TO247, Discrete Semiconductor Products~Transistors - IGBTs - Single
STGWA40H65DFB, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
