STGWA30IH65DF Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: TRENCH GATE FIELD-STOP 650 V, 30
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STGWA30IH65DF Specifications:
- MfrPart.: STGWA30IH65DF
- Mfr: STMicroelectronics
- Description: TRENCH GATE FIELD-STOP 650 V, 30
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: IH
- PartStatus: Active
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 650 V
- Current-Collector(Ic)(Max): 60 A
- Current-CollectorPulsed(Icm): 90 A
- Vce(on)(Max)@VgeIc: 2.05V @ 15V, 30A
- Power-Max: 180 W
- SwitchingEnergy: 123µJ (off)
- InputType: Standard
- GateCharge: 80 nC
- Td(on/off)@25°C: -/200ns
- TestCondition: 400V, 30A, 22Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- STGWA30IH65DF STMicroelectronics, TRENCH GATE FIELD-STOP 650 V, 30, Discrete Semiconductor Products~Transistors - IGBTs - Single
STGWA30IH65DF, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
