STGWA15S120DF3 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT 1200V 15A TO247-3L
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STGWA15S120DF3 Specifications:
- MfrPart.: STGWA15S120DF3
- Mfr: STMicroelectronics
- Description: IGBT 1200V 15A TO247-3L
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 30 A
- Current-CollectorPulsed(Icm): 60 A
- Vce(on)(Max)@VgeIc: 2.05V @ 15V, 15A
- Power-Max: 259 W
- SwitchingEnergy: 540µJ (on), 1.38mJ (off)
- InputType: Standard
- GateCharge: 53 nC
- Td(on/off)@25°C: 23ns/140ns
- TestCondition: 600V, 15A, 22Ohm, 15V
- ReverseRecoveryTime(trr): 270 ns
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- STGWA15S120DF3 STMicroelectronics, IGBT 1200V 15A TO247-3L, Discrete Semiconductor Products~Transistors - IGBTs - Single
