STGW80H65DFB-4 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-4
- Description: IGBT BIPO 650V 80A TO247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STGW80H65DFB-4 Specifications:
- MfrPart.: STGW80H65DFB-4
- Mfr: STMicroelectronics
- Description: IGBT BIPO 650V 80A TO247
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 650 V
- Current-Collector(Ic)(Max): 120 A
- Current-CollectorPulsed(Icm): 240 A
- Vce(on)(Max)@VgeIc: 2V @ 15V, 80A
- Power-Max: 469 W
- SwitchingEnergy: 2.1mJ (on), 1.5mJ (off)
- InputType: Standard
- GateCharge: 414 nC
- Td(on/off)@25°C: 84ns/280ns
- TestCondition: 400V, 80A, 10Ohm, 15V
- ReverseRecoveryTime(trr): 85 ns
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-4
- STGW80H65DFB-4 STMicroelectronics, IGBT BIPO 650V 80A TO247, Discrete Semiconductor Products~Transistors - IGBTs - Single
