STGW75M65DF2 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: TRENCH GATE FIELD-STOP IGBT M SE
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STGW75M65DF2 Specifications:
- MfrPart.: STGW75M65DF2
- Mfr: STMicroelectronics
- Description: TRENCH GATE FIELD-STOP IGBT M SE
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: M
- PartStatus: Active
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 650 V
- Current-Collector(Ic)(Max): 120 A
- Current-CollectorPulsed(Icm): 225 A
- Vce(on)(Max)@VgeIc: 2.1V @ 15V, 75A
- Power-Max: 468 W
- SwitchingEnergy: 690µJ (on), 2.54mJ (off)
- InputType: Standard
- GateCharge: 225 nC
- Td(on/off)@25°C: 47ns/125ns
- TestCondition: 400V, 75A, 3.3Ohm, 15V
- ReverseRecoveryTime(trr): 165 ns
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- STGW75M65DF2 STMicroelectronics, TRENCH GATE FIELD-STOP IGBT M SE, Discrete Semiconductor Products~Transistors - IGBTs - Single
