STGW40S120DF3 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT 1200V 40A TO247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STGW40S120DF3 Specifications:
- MfrPart.: STGW40S120DF3
- Mfr: STMicroelectronics
- Description: IGBT 1200V 40A TO247
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 80 A
- Current-CollectorPulsed(Icm): 160 A
- Vce(on)(Max)@VgeIc: 2.15V @ 15V, 40A
- Power-Max: 468 W
- SwitchingEnergy: 1.43mJ (on), 3.83mJ (off)
- InputType: Standard
- GateCharge: 129 nC
- Td(on/off)@25°C: 35ns/148ns
- TestCondition: 600V, 40A, 15Ohm, 15V
- ReverseRecoveryTime(trr): 355 ns
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- STGW40S120DF3 STMicroelectronics, IGBT 1200V 40A TO247, Discrete Semiconductor Products~Transistors - IGBTs - Single
STGW40S120DF3, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
