STGW30N90D Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT 900V 60A 220W TO247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STGW30N90D Specifications:
- MfrPart.: STGW30N90D
- Mfr: STMicroelectronics
- Description: IGBT 900V 60A 220W TO247
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: PowerMESH™
- PartStatus: Obsolete
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 900 V
- Current-Collector(Ic)(Max): 60 A
- Current-CollectorPulsed(Icm): 135 A
- Vce(on)(Max)@VgeIc: 2.75V @ 15V, 20A
- Power-Max: 220 W
- SwitchingEnergy: 1.66mJ (on), 4.44mJ (off)
- InputType: Standard
- GateCharge: 110 nC
- Td(on/off)@25°C: 29ns/275ns
- TestCondition: 900V, 20A, 10Ohm, 15V
- ReverseRecoveryTime(trr): 152 ns
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- STGW30N90D STMicroelectronics, IGBT 900V 60A 220W TO247, Discrete Semiconductor Products~Transistors - IGBTs - Single
STGW30N90D, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
