STGW15H120F2 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT H-SERIES 1200V 15A TO-247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STGW15H120F2 Specifications:
- MfrPart.: STGW15H120F2
- Mfr: STMicroelectronics
- Description: IGBT H-SERIES 1200V 15A TO-247
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 30 A
- Current-CollectorPulsed(Icm): 60 A
- Vce(on)(Max)@VgeIc: 2.6V @ 15V, 15A
- Power-Max: 259 W
- SwitchingEnergy: 380µJ (on), 370µJ (off)
- InputType: Standard
- GateCharge: 67 nC
- Td(on/off)@25°C: 23ns/111ns
- TestCondition: 600V, 15A, 10Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- STGW15H120F2 STMicroelectronics, IGBT H-SERIES 1200V 15A TO-247, Discrete Semiconductor Products~Transistors - IGBTs - Single
STGW15H120F2, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
