STGP3HF60HD Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-220-3
- Description: IGBT BIPO 600V 3A TO220
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STGP3HF60HD Specifications:
- MfrPart.: STGP3HF60HD
- Mfr: STMicroelectronics
- Description: IGBT BIPO 600V 3A TO220
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 7.5 A
- Current-CollectorPulsed(Icm): 18 A
- Vce(on)(Max)@VgeIc: 2.95V @ 15V, 1.5A
- Power-Max: 38 W
- SwitchingEnergy: 19µJ (on), 12µJ (off)
- InputType: Standard
- GateCharge: 12 nC
- Td(on/off)@25°C: 11ns/60ns
- TestCondition: 400V, 1.5A, 100Ohm, 15V
- ReverseRecoveryTime(trr): 85 ns
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-220-3
- STGP3HF60HD STMicroelectronics, IGBT BIPO 600V 3A TO220, Discrete Semiconductor Products~Transistors - IGBTs - Single
STGP3HF60HD, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
