STGP19NC60KD Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-220-3
- Description: IGBT 600V 35A 125W TO220
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STGP19NC60KD Specifications:
- MfrPart.: STGP19NC60KD
- Mfr: STMicroelectronics
- Description: IGBT 600V 35A 125W TO220
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: PowerMESH™
- PartStatus: Active
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 35 A
- Current-CollectorPulsed(Icm): 75 A
- Vce(on)(Max)@VgeIc: 2.75V @ 15V, 12A
- Power-Max: 125 W
- SwitchingEnergy: 165µJ (on), 255µJ (off)
- InputType: Standard
- GateCharge: 55 nC
- Td(on/off)@25°C: 30ns/105ns
- TestCondition: 480V, 12A, 10Ohm, 15V
- ReverseRecoveryTime(trr): 31 ns
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-220-3
- STGP19NC60KD STMicroelectronics, IGBT 600V 35A 125W TO220, Discrete Semiconductor Products~Transistors - IGBTs - Single
STGP19NC60KD, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
